Special Products

Gratings are regularly placed parallel elongated elements perpendicular to each other generally forming a mesh

Methods Of Manufacturing :

Hand moulding where glassfibers are manually put along with resin & compressed properly in matrix moulds to make grating Pultrusion

MOC

  • Isophthalic resin
  • Normal Vinylester resin
  • Special Vinylester resin
  • Fire retardant resin
  • PP gratings are used as internals in scrubbers & fume exhaust systems

  • Advantages :

  • Do not corrode like metal,can be custom made for different corrosive environments
  • Good in corrosion environments
  • Lower maintenance cost
  • Anti slip
  • Standard designed for 500 Kg/m2, can be designed for higher loads

  • Use :

  • Bridge decks, filters & steps, tank farm structures, drain covering
  • Stair treds
  • Onshore / Ofshore platform
  • Flooring in acid washing areas

  • Technical specifications :

  • Size : 1mx1m
  • Mesh : 30mm x 30mm
  • Thickness : 10 mm peripheral ribs & 8 mm internal ribs

  • Weight carrying capacity : 500 Kg/m2
